Avery Weigh-Tronix AWT05-508311: A60 alarm for 2060 Scale Indicator
Easy to Install on all 2060 indicators
8-pin connector
Rugged; Ideal for Outdoors
Highly Visible
Adjustable Volume
The A60 Audible and Visual Alarm from Avery Weigh-Tronix is built with durability and flexibility in mind. Ideal solution for users that need a brighter alarm light or louder audible alarm than the one offered on the weight indicator. Excellent solution for mounting on TMR mixers and seed tenders.Includes standard stainless steel bracket to easily mount on equipment or building structure.
FEATURES & BENEFITS•
Highly Visible – High brightness, high-resolution red LED provides clear visibility of alarm light in all lighting and weather conditions
Adjustable Volume – Simply twist the audible alarm cover to adjust the sound volume. Loud enough to use outdoors in noisy environments and with cover closed quiet enough to comfortably and safely use inside
Durable – Designed to withstand the harshest Agriculture environments with IEC IP67 rating. Completely dust and water tight (water immersion up to 1 minute)
SPECIFICATIONS
Audible Alarm: 2.9 KHz ± 250 Hz oscillation frequency;maximum intensity 94 db at 3.3 ft (1 m) (typical)
Visual Alarm: Red LED
Enclosure: ABS enclosure with polycarbonate cover for LED light Environmental Rating: IEC IP67
Operating Temperature: -4° F to +122° F (-20° C to +50° C)
Max. Rel. Humidity: 95% at 122° F (50° C) (non-condensing)
Power: 12 to 30 VDC (10% max. ripple); or 21 to 27 VAC
Supply Protection Circuitry: Protected against reverse polarity and transient voltages
Weight: 11 oz (0.31 kg)Shipping Weight: 1 lb (0.45 kg)
Agencies: CE Approved and UL Listed
Warranty: Three years
